Genuine Hobbywing
Features:
• Water-proof and dust-proof, suitable for all-weather condition races.
• Small size with built-in capacitor module.
• Three running modes: Fwd/Br, Fwd/Rev/Br and Fwd/Rev, fits for various vehicles.（Note 1: Fwd =Forward, Br=Brake, Rev=Reverse.）
• Great current endurance capability.
• Great built-in BEC output capacity.
• Automatic throttle range calibration, easy to use.
• Easy to set the ESC parameters with jumpers.
• Multiple protections: Low voltage cut-off protection for battery / Over-heat protection / Throttle signal loss protection.
Specifications：
Fwd. Cont. / Peak Current ：60A/360A
Rev. Cont. / Peak Current：30A/180A
Voltage Range：2-3S Lipo or 5-9 NiMH
Cars Applicable：1/10: Touring Car, Buggy, Short Course Truck, Monster, Truggy, Rock Crawler and Tank
Motor Limit：
2S Lipo or 6 NiMH : 540 or 550 Size Motor: ≥12T or RPM<30000 @7.2V
3S Lipo or 9 NiMH: 540 or 550 Size Motor: ≥18T or RPM<20000@7.2V
Resistance:Fwd 0.001Ω, Rev 0.002Ω
BEC Output:3A / 6V (Switch Mode)
Dimension / Weight:36.5x32x18mm / 39 g
Cooling Fan:Without cooling fan
Running Modes：Forward / Reverse / Brake, Forward / Brake, Forward / Reverse
Instruction manual : Click here
